Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter

Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter

  • हाई लाइट

    honeycomb ceramic catalytic converter

    ,

    ceramic catalyst support

  • cells density
    7~400 CPSI
  • Material
    Cordierite
  • Size
    Customize
  • Color
    White
  • Name
    ceramic honeycomb|ceramic substrates
  • shape
    squareness
  • usage
    3 way catalytic converters
  • Place of Origin
    China.Yixing
  • ब्रांड नाम
    Yuxing
  • प्रमाणन
    ISO9001 TS/16949
  • Minimum Order Quantity
    NO
  • Packaging Details
    Standard export packing
  • Delivery Time
    5 work days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    6million liter/year

Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter

Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter





Description:



After coated with catalyst, the product is widely applied in organic waste gas purification, heat exchange system industrial waste gas treatment, coal-fired power plant flue gas purification, NOx purification system, garbage incineration and harmful gas purification treatment, etc.Benefits of Products:

● Large Surface Area

● Low thermal expansion coefficient

● Good thermal shock and thermal shock performance

● Good corrosion resistant performance





2    1.Product use

After coated with catalyst, the product is widely applied in organic waste gas purification, heat exchange system industrial waste gas treatment, coal-fired power plant flue gas purification, NOx purification system, garbage incineration and harmful gas purification treatment, etc.


2.Overall dimensions standards

Item



Standard values

Allowance

Remark

boundary dimension

length

150MM

±1.5MM



width

150MM

±1.5MM



height

50-100MM

±1.0MM



101-300MM

±1%MM*height



verticality

height

50-100MM

≤1MM



101-300MM

≤1%Height



parallelism

height

50-100MM

≤1MM



101-300MM

≤1%height





Item

Standard

values



Test

methodS



chemical component



Al2O3

35.2%±1%

Chemical titration

 analysis

SiO2

50.9%±1%

MgO

13.9%±1%

Cordierite main crystalline

 phase content

≥90%

X-ray diffraction

RT Mpa

AAxis

≥15 Mpa

universal material

testing machine

BBxis

≥2 Mpa

water absorption

23%-27%

Gravimetric method

softening temperature

≥1320℃

high-temperature electric resistance furnace

CET(800℃)

≤1.6*10-6/℃

thermal dilatometer







Applications:



After coated with catalyst, the product is widely applied in organic waste gas purification, heat exchange system industrial waste gas treatment, coal-fired power plant flue gas purification, NOx purification system, garbage incineration and harmful gas purification treatment, etc.





Specifications



Cell density (CPSI):7~400



Item

(mm)

Sectional Dimension

(mm2)

Area of Section



Shape of Section

(mm)

Height

1

50×50

2500

Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter 0



The height can be designed by customer

2

50×50

2500

Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter 1

3

100x100

10000

Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter 2

4

150x150

22500

Gas Honeycomb Ceramic Substrate With 3 Way Catalytic Converter 3





REMARK: The SIZE can be designed by customer





Competitive Advantage:



● Large Surface Area

● Low thermal expansion coefficient

● Good thermal shock and thermal shock performance

● Good corrosion resistant performance
